Product Function
|
Standards |
5GHz: IEEE 802.11ax/ac/n/a 2.4GHz: IEEE 802.11ax/n/b/g SuMESH supported |
|
MIMO |
MU-MIMO Beamforming |
|
Bandwidth |
5GHz: 20/40/80/160MHz 2.4GHz: 20/40MHz |
|
Transmission rate |
5GHz: 2400Mbps 2.4GHz: 600Mbps
|
|
Operation channels |
5GHz: 34, 36, 38, 40, 42, 44, 46, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 5GHz DFS: 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140 2.4GHz: 1-13 |
|
Transmission power for 2.4GHz |
-87dBm @ 802.11b -73dBm @ 802.11g -68dBm @ 802.11n 20MHz MCS7 -64dBm @ 802.11n 40MHz MCS7 -22dBm @ 802.11ax EVM-15 CCK-1M -20dBm @ 802.11ax EVM-30 OFDM-54M -20dBm @ 802.11ax EVM-30 40MHz MCS7 -18dBm @ 802.11ax EVM-41 40MHz MCS11 |
|
Transmission power for 5GHz |
-76dBm @ 802.11a -72dBm @ 802.11n 20MHz MCS7 -69dBm @ 802.11n 40MHz MCS7 -70dBm @ 802.11ac 20MHz MCS8 -65dBm @ 802.11ac 40MHz MCS9 -61dBm @ 802.11ac 80MHz MCS9 -22dBm @ 802.11ax EVM-15 OFDM-6M -20dBm @ 802.11ax EVM-30 OFDM-54M -20dBm @ 802.11ax EVM-30 40MHz MCS7 -19dBm @ 802.11ax EVM-32 VHT80 MCS9 -18dBm @ 802.11ax EVM-41 HE80-MCS11 |
|
WiFi Encryption |
WPA, WPA2 and WPA3 with AES |
|
Working mode |
Router Access point |
|
Layer 3 function |
Port forwarding PPPoE/Static IP/DHCP NAT/NAPT ALG, UPnP DDNS/DNS server/DNS client IPv6/IPv4 dual stack Static/Default routes |
|
Security |
Firewall Filtering based on MAC/IP/URL addresses Access control |
