Interface parameters
|
GPON/EPON port |
GPON: FSAN G.984.2 standard, Class B+/C+/C++ EPON: 1000BASE-PX20+ symmetrical, CTC2.1, CTC3.0 GPON: 2.488/1.244Gbps downstream/upstream EPON: 1.25 Gbps downstream/upstream Wavelength: Transmit 1310nm, Receiver 1490nm Receiver sensitivity: GPON: -28dBm; EPON: -27dBm Optical power transmission: GPON: 0.5~5dBm; EPON: 0~4dBm SC/PC singlemode fiber Saturation optical power: GPON: -8dBm; EPON: -3dBm Flexible mapping between GEM Port and TCONT GPON: Consistent with SN or password authentication defined in G.984.3 EPON: Consistent with MAC or LOID authentication defined in IEEE 802.3ah Bidirectional FEC SR-DBA and NSR-DBA Type B (single and dual homing) |
|
Ethernet port |
Ethernet port-based VLAN tagging and tag removal Transparent transmission 1:1 VLAN, N:1 VLAN or VLAN QinQ VLAN Limit on the number of MAC addresses learned MAC address learning Self-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s Full/Half Duplex Mode Automatic MDI/MDI-X |
|
POTS port |
Maximum REN: 4 G.711A/μ, G.729a/b and G.722 encoding/decoding T.30/T.38/G.711 fax mode DTMF Supports SIP protocol |
|
WiFi |
AC1500, complies with IEEE 802.11a/b/g/n @ 2.4GHz and IEEE 802.11a/b/g/n/ac @ 5GHz 5dBi antenna gain Ideal maximum speed up to 900Mbps@5GHz and 300Mbps@2.4GHz 2.4GHz supports 2*2 MIMO technology, 5GHz supports 2*2 MIMO technology WMM/Multiple SSID/WPS Compatible with SuMesh |
Product Function
|
Smart O&M |
Unauthorized UN detection Loop detection Dying gas detection and reporting Compatible with conventional OLT Auto registration/link detection/remote update OMCI Management /WEB/TR069 Backup and Restore Settings VLAN transparent/tag/untag MAC address learning, supports 4096 MAC table Supports preset function Support Timer Reset |
|
Basic Service |
Bridged access and routing to the Internet Voice Service Setup |
|
Wireless |
AC1200, complies with IEEE 802.11a/b/g/n @ 2.4GHz and IEEE 802.11a/b/g/n/ac @ 5GHz Maximum 8 SSIDs Hide SSID Supports wider RF bandwidth, up to 80MHz@5G, 40MHz@2.4G Supports 64/128-bit WEP, 802.1x, WPA, and WPA2 wireless security Compatible with cable mesh |
|
Layer 3 Function |
Port forwarding PPPoE/Static IP/DHCP NAT/TNA ALG, UPnP DDNS/DNS server/DNS client IPv6/IPv4 Dual Stack and DS-Lite Static/Default Routes Multiple services on one WAN port |
|
quality of service |
Limiting Ethernet port speed Priority label SP/WRR/SP+WRR queue scheduling Traffic shaping Avoid congestion Limiting the rate of broadcast packets |
|
Multicast |
Multicast version 2.0 Multicast VLAN Configuration Transparent multicast/snooping/proxy Quick exit function |
