GPON/EPON Port |
GPON: FSAN G.984.2 standard, Class B+ EPON: 1000 BASE-PX20+ Symmetrical, CTC2.1, CTC3.0 GPON: 2.488/1.244 Gbps downstream/upstream EPON: 1.25 Gbps downstream/upstream Wavelength: Transmit 1310nm, Receiver 1490nm Reception Sensitivity: GPON: -28 dBm; EPON: -27 dBm Transmit optical power: GPON: 0.5 to 5 dBm; EPON: 0-4 dBm SC/PC singlemode fiber Optical Saturation Power: GPON: -8 dBm; EPON: -3dBm Flexible mapping between GEM port and TCONT GPON: Consistent with SN or password authentication defined in G.984.3 EPON: Consistent with MAC or LOID authentication defined in IEEE 802.3 ah Bidirectional FEC SR-DBA and NSR-DBA Type B (single accommodation and double accommodation) |
|
Port |
VLAN tagging and untagging based on Ethernet ports VLAN 1:1, VLAN N:1 or VLAN transparent transmission QinQ VLAN Limit on the number of MAC addresses learned Mac Address Learning 1 GE self-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s 1 self-adaptive FE 10 Mbit/s and 100 Mbit/s Full/Half Duplex Mode Auto MDI/MDI-X |
|
WLAN |
Complies with IEEE 802.11 a/b/g/n protocol standard, supports 2.4 GHz 5 dBi antenna gain Ideal maximum speed up to 300Mbps 2.4 GHz supports MIMO technology Encryption mode AES, TKIP, WPA, WPA2, WPA-PSK/WPA2-PSK |
|
CATV |
Wavelength: 1550nm RF frequency: 45 MHz - 1000 MHz RF output level: >86 dBuV RF output return loss: >10 dB RF output impedance: 75 Ω CNR: >42dB; CSO: <-60 dBc; CTB: -65 dBc |
Product Function
|
Smart O&M |
Rogue UN Detection Loop detection Dying gas detection and reporting Compatible with FiberHome, ZTE and HUAWEI OLT |
|
Basic Service |
Bridge and Internet Access Routing Mode IPTV Service Setup CATV Service Configuration |
|
Wireless (Optional) |
IEEE802.11 a/b/g/n/ac standard, 2.4G and 5G Maximum 8 SSIDs Hide SSID Supports wider RF bandwidth, up to 80MHz@5G, 40MHz@2.4G Supports higher 256-QAM modulation mode Support MIMO-OFDM coding mode Supports 64/128-bit WEP, 802.1 x, WPA and WPA2 wireless security |
|
Layer 3 Function |
Port forwarding PPPoE/Static IP/DHCP NAT/NAPT ALG, UPnP DDNS/DNS server/DNS client Dual stack IPv6/IPv4, and DS-Lite Static/Default Routes Multiple services on one WAN port |
|
QoS |
Limiting Ethernet port speed Priority label SP/WRR/SP+WRR queue scheduling Traffic shaping Congestion avoidance Packet transmission rate limiting |
|
Energy Saving |
Power saving indicator Learn about GPON energy saving of G987.3 protocol |
|
Security |
Firewall Filtering based on MAC/IP/URL addresses Access control |
|
Common O&M |
Auto registration/link detection/remote update Management OMCI/WEB/TR069 Backup and Restore Settings Transparent/Tag/Untagged VLAN Mac address learning, support for MAC table 4096 Supports preset function Restart at scheduled time |
|
Multicast |
Multicast VLAN Configuration Transparent multicast/snooping/proxy |
