Interface parameters
|
GPON/EPON port |
GPON: FSAN G.984.2 standard, Class B+/C+/C++ EPON: 1000BASE-PX20+ Symmetric, CTC2.1, CTC3.0 GPON: 2.488/1.244Gbps Downstream/Upstream EPON: 1.25Gbps Downstream/Upstream Wavelength: Transmit 1310nm, Receiver 1490nm Receiver Sensitivity: GPON: -28dBm; EPON: -27dBm Transmit Optical Power: GPON: 0.5~5dBm; EPON: 0~4dBm SC/PC single-mode fiber Saturation Optical Power: GPON: -8dBm; EPON: -3dBm Flexible mapping between GEM Port and TCONT GPON: Consistent with the SN or password authentication defined in G.984.3 EPON: Consistent with the MAC or LOID authentication defined in IEEE 802.3ah Bi-directional FEC SR-DBA and NSR-DBA Type B (single-homing & dual-homing |
|
Ethernet port |
Ethernet port-based VLAN tags and tag removal 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission QinQ VLAN Limit on the number of learned MAC addresses MAC address learning Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s Full/half duplex mode Auto MDI/MDI-X |
|
POTS port |
Maximum REN: 4 G.711A/μ, G.729a/b and G.722 encoding/decoding T.30/T.38/G.711 fax mode DTMF Support SIP protoco |
|
USB port |
USB 3.0 interface Maximum ideal transmission rate: 5Gbps FTP-based network storage File/Print sharing based on SAMBA DLNA function |
|
WiFi |
Comply with IEEE 802.11a/b/g/n/ac/ax protocol standard, support 2.4GHz and 5GHz 5dBi antenna gain Maximum ideal rate up to 2.4Gbps@5GHz and 600Mb 2.4GHz supports 2*2 MIMO technology 5GHz supports 2*2 MIMO technology WMM/Multiple SSIDs/WPS |
Product Function
|
Smart O&M |
Rogue ONU detection Loop detection Dying-Gas detection and reporting Compatible with FiberHome, ZTE and HUAWEI OLT |
|
Basic Service |
Bridge and routing mode access Internet IPTV service configuration Voice service configuration |
|
Wireless |
AX3000, IEEE802.11a/b/g/n/ac/ax standard, 2.4G and 5G Maximum 8 SSID Hide SSID Support wider RF bandwidth, up to 160MHz@5G, 40MHz@2.4G Support higher 1024-QAM modulation mode Support MU-MIMO encoding mode Support wireless security of 64/128 bit WEP, 802.1x, WPA, WPA2 and WPA3 SuMesh Supported |
|
Layer 3 Function |
Port forwarding PPPoE/Static IP/DHCP NAT/NAPT ALG, UPnP DDNS/DNS server/DNS client IPv6/IPv4 dual stack, and DS-Lite Static/Default routes Multiple services on one WAN port |
|
Quality of Service |
Ethernet port rate limitation Priority tag SP/WRR/SP+WRR queue schedule Traffic shaping Congestion avoidance Broadcast packet rate limitation |
|
Power Saving |
Indicator power saving Meet GPON energy saving of G987.3 protocol |
|
Security |
Firewall Filtering based on MAC/IP/URL addresses and access control |
|
Common O&M |
Automatic registration / link detection / remote upgrade OMCI /WEB/TR069 management Backup and Restore configuration VLAN transparent/tag/untag MAC address learning, support 4096 MAC table Support PreSet function Support timer reboot |
|
Multicast |
Multicast version 2.0 Multicast VLAN configuration Multicast transparent/snooping/proxy Fast leave function |
